Procesador .
- Soporte para procesadores Intel 9000 y 8th Generation Intel® Core™. i7 processors/Intel® Core™. i5 processors/Intel® Core™. i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
- L3 cache varies with CPU
-
Chipset .
- Intel® Z390 Express Chipset
-
Memoria .
. - 4 x DDR4 DIMM que soportan hasta 64 GB of system memory
- Dual channel memory architecture
- Soporte para DDR4 2666/2400/2133 MHz memory modules
- Soporte para ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
- Soporte para non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Soporte para Extreme Memory Profile (XMP) memory modules
- (Please refer 'Memory Support List' for more information.)
-
Gráficos Integrados
- Integrated Graphics Processor-Intel® HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
- * Soporte para HDMI 1.4 version and HDCP 2.2.
- Máxima memoria compartida 1 GB
-
Audio .
. - Realtek® ALC887 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
- * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
- Soporte para S/PDIF Out
-
LAN .
- Realtek® GbE LAN chip (10/100/1000 Mbit)
-
Puertos de Expansión .
. . - 1 x PCI Express x16 slot, running at x16 (PCIEX16)
- * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
- 2 x PCI Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)
- 3 x PCI Express x1 slots
- (All of the PCI Express slots conform to PCI Express 3.0 standard.)
-
Interfaz de Almacenamiento .
. - Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support, prepared for Intel® Hybrid SSD)
- 6 x SATA 6Gb/s connectors
- Soporte para RAID 0, RAID 1, RAID 5, and RAID 10
- * Refer to '1-7 Internal Connectors,' for the installation notices for the M.2 and SATA connectors.
- Intel® Optane™. Memory Ready
-
Tecnología Multi-Gráficos .
. - Soporte para AMD Quad-GPU CrossFire™. and 2-Way AMD CrossFire™. technologies
-
USB .
- Chipset:
- 8 x USB 3.1 Gen 1 ports (6 ports on the back panel, 2 ports available through the internal USB header)
- 2 x USB 2.0/1.1 ports available through the internal USB header
-
Conectores Internos de E/S .
. - 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x 4-pin ATX 12V power connector
- 1 x M.2 Socket 3 connector
- 6 x SATA 6Gb/s connectors
- 1 x CPU fan header
- 3 x system fan headers
- 1 x RGB LED strip header
- 1 x front panel header
- 1 x front panel audio header
- 1 x USB 3.1 Gen 1 header
- 1 x USB 2.0/1.1 header
- 1 x S/PDIF Out header
- 1 x Thunderbolt™. add-in card connector
- 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
- 1 x serial port header
- 1 x Clear CMOS jumper
-
Conectores del Panel Trasero
- 1 x PS/2 mouse port
- 1 x PS/2 Keyboard port
- 1 x HDMI port
- 6 x USB 3.1 Gen 1 ports
- 1 x RJ-45 port
- 3 x audio jacks
-
Controlador de E/S
. . - iTE® I/O Controller Chip
- Monitorización H/W . .
- Voltage detection
- Temperature detection
- Fan speed detection
- Overheating warning
- Fan fail warning
- Fan speed control
- * Whether the fan speed control function is supported will depend on the fan you install.
-
BIOS
- 1 x 128 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
-
Sistema Operativo
- Soporte para Windows 10 64-bit
-
Diseño
. - ATX Form Factor. 30.5cm x 23.0cm
Ficha técnica
- Marca
- GIGABYTE
- SOCKET
- Socket 1151 Gen 8 - 9
- Tipo de Memoria
- Memoria DDR4
- Chipset
- Z390
- Factor de Forma
- ATX
- Zocalos RAM
- 4 zocalos
- InterFace de Disco M.2
- 1 Ranuras M.2
